SMD Fluorescent

ITEM NO.	SPECIFICATIONS
AH801-M312S1	Dimension	L 1213mm * ∮30	TYPE OF LED	SMD3528
	Power Consumption	22W	Environment temperature	-20 ~ +45
	Tube Material	Aluminum +milky PC	Environment Humidity	<95%
	Pin Type	G13	Color Rendering Index	>80Ra(White)
	LED Quantity	312	Color Rendering Index	>85Ra(Warm White)
	Luminous efficiency	110lm/W	Power Factor	≥0.88
	Input Voltage	85-265V	Equal To Traditional Fluorescent	60W
	Work Frequency	50-60HZ	Single LED Intensity (LM)	6.5-7.0lm
	Color Temperature	4000 ~ 4500K 5500~ 6000K	Luminous Flux (LM)	1800lm±5%
	Viewing Angle (Deg)	170	Luminance: 2-3M High (Lux)	3M≥65LUX 2M≥110LUX
AH801-M276S1	Dimension	L 1213mm * ∮30	TYPE OF LED	SMD3528
	Power Consumption	19W	Environment temperature	-20 ~ +45
	Tube Material	Aluminum +milky PC	Environment Humidity	<95%
	Pin Type	G13	Color Rendering Index	>80Ra(White)
	LED Quantity	276	Color Rendering Index	>85Ra(Warm White)
	Luminous efficiency	110lm/W	Power Factor	≥0.88
	Input Voltage	85-265V	Equal To Traditional Fluorescent	45W
	Work Frequency	50-60HZ	Single LED Intensity (LM)	6.5-7.0lm
	Color Temperature	4000 ~ 4500K 5500 ~ 6000K	Luminous Flux (LM)	1550lm±5%
	Viewing Angle (Deg)	170	Luminance: 2-3M High (Lux)	3M≥60LUX 2M≥100LUX
AH801-T312S1	Dimension	L 1213mm * ∮30	TYPE OF LED	SMD3528
	Power Consumption	22W	Environment temperature	-20 ~ +45
	Tube Material	Aluminum +transparent PC	Environment Humidity	<95%
	Pin Type	G13	Color Rendering Index	>80Ra(White)
	LED Quantity	312	Color Rendering Index	>85Ra(Warm White)
	Luminous efficiency	110lm/W	Power Factor	≥0.88
	Input Voltage	85-265V	Equal To Traditional Fluorescent	65W
	Work Frequency	50-60HZ	Single LED Intensity (LM)	6.5-7.0lm
	Color Temperature	4000 ~ 4500K 5500~ 6000K	Luminous Flux (LM)	2000lm±5%
	Viewing Angle (Deg)	170	Luminance: 2-3M High (Lux)	3M≥105LUX 2M≥180LUX
AH801-T276S1	Dimension	L 1213mm * ∮30	TYPE OF LED	SMD3528
	Power Consumption	19W	Environment temperature	-20 ~ +45
	Tube Material	Aluminum +transparent PC	Environment Humidity	<95%
	Pin Type	G13	Color Rendering Index	>80Ra(White)
	LED Quantity	276	Color Rendering Index	>85R (Warm White)
	Luminous efficiency	110lm/W	Power Factor	≥0.88
	Input Voltage	85-265V	Equal To Traditional Fluorescent	45W
	Work Frequency	50-60HZ	Single LED Intensity (LM)	6.5-7.0lm
	Color Temperature	4000 ~ 4500K 5500 ~ 6000K	Luminous Flux (LM)	1750lm±5%
	Viewing Angle (Deg)	170	Luminance: 2-3M High (Lux)	3M≥93LUX 2M≥160LUX
AH801-T240S1	Dimension	L 1213mm * ∮30	TYPE OF LED	SMD3528
	Power Consumption	16W	Environment temperature	-20 ~ +45
	Tube Material	Aluminum +transparent PC	Environment Humidity	<95%
	Pin Type	G13	Color Rendering Index	>80Ra(White)
	LED Quantity	240	Color Rendering Index	>85Ra(Warm White)
	Luminous efficiency	110lm/W	Power Factor	≥0.88
	Input Voltage	85-265V	Equal To Traditional Fluorescent	36W
	Work Frequency	50-60HZ	Single LED Intensity (LM)	6.5-7.0lm
	Color Temperature	4000 ~ 4500K 5500 ~ 6000K	Luminous Flux (LM)	1500lm±5%
	Viewing Angle (Deg)	170	Luminance: 2-3M High (Lux)	3M≥80LUX 2M≥138LUX
AH801-W240S1	Dimension	L 1213mm * ∮30	TYPE OF LED	SMD3528
	Power Consumption	16W	Environment temperature	-20 ~ +45
	Tube Material	Aluminum +stripe PC	Environment Humidity	<95%
	Pin Type	G13	Color Rendering Index	>80Ra(White)
	LED Quantity	240	Color Rendering Index	>85Ra(Warm White)
	Luminous efficiency	110lm/W	Power Factor	≥0.88
	Input Voltage	85-265V	Equal To Traditional Fluorescent	36W
	Work Frequency	50-60HZ	Single LED Intensity (LM)	6.5-7.0lm
	Color Temperature	4000 ~ 4500K 5500 ~ 6000K	Luminous Flux (LM)	1500lm±5%
	Viewing Angle (Deg)	170	Luminance: 2-3M High (Lux)	3M≥80LUX 2M≥138LUX
AH801-W276S1	Dimension	L 1213mm * ∮30	TYPE OF LED	SMD3528
	Power Consumption	19W	Environment temperature	-20 ~ +45
	Tube Material	Aluminum +stripe PC	Environment Humidity	<95%
	Pin Type	G13	Color Rendering Index	>80Ra(White)
	LED Quantity	276	Color Rendering Index	>85Ra(Warm White)
	Luminous efficiency	110lm/W	Power Factor	≥0.88
	Input Voltage	85-265V	Equal To Traditional Fluorescent	45W
	Work Frequency	50-60HZ	Single LED Intensity (LM)	6.5-7.0lm
	Color Temperature	4000 ~ 4500K 5500 ~ 6000K	Luminous Flux (LM)	1750lm±5%
	Viewing Angle (Deg)	170	Luminance: 2-3M High (Lux)	3M≥93LUX 2M≥160LUX
